Description
Precision 3660 Tower Technical Specifications
System Information
Processor
12th Generation Intel® Core™ i3-12100 (12 MB cache, 4 cores, 8 threads, 3.30 GHz to 4.30 GHz, 60 W)
12th Generation Intel® Core™ i5-12500 (18 MB cache, 6 cores, 12 threads, 3.00 GHz to 4.60 GHz, 65 W)
12th Generation Intel® Core™ i5-12600 (18 MB cache, 6 cores, 12 threads, 3.30 GHz to 4.80 GHz, 65 W)
12th Generation Intel® Core™ i7-12700 (25 MB cache, 12 cores, 20 threads, 2.10 GHz to 4.90 GHz, 65 W)
12th Generation Intel® Core™ i9-12900 (30 MB cache, 16 cores, 24 threads, 2.40 GHz to 5.10 GHz, 65 W)
12th Generation Intel® Core™ i5-12500 (18 MB cache, 6 cores, 12 threads, 3.00 GHz to 4.60 GHz, 65 W)
12th Generation Intel® Core™ i5-12600 (18 MB cache, 6 cores, 12 threads, 3.30 GHz to 4.80 GHz, 65 W)
12th Generation Intel® Core™ i7-12700 (25 MB cache, 12 cores, 20 threads, 2.10 GHz to 4.90 GHz, 65 W)
12th Generation Intel® Core™ i9-12900 (30 MB cache, 16 cores, 24 threads, 2.40 GHz to 5.10 GHz, 65 W)
Operating System
Windows 11 Home, 64-bit
Windows 11 Pro, 64-bit
Windows 11 Pro National Academic, 64-bit
Windows 10 Pro (Includes Windows 11 Pro License), 64-bit
Ubuntu® 20.04 LTS, 64-bit
Windows 11 Pro, 64-bit
Windows 11 Pro National Academic, 64-bit
Windows 10 Pro (Includes Windows 11 Pro License), 64-bit
Ubuntu® 20.04 LTS, 64-bit
Memory & Storage
Memory Options
Up to 128 GB, 4 x 32 GB, DDR5, 4400 MHz, ECC/Non-ECC
(Note: Speed fluctuates based on configuration)
(Note: Speed fluctuates based on configuration)
Storage Support
Up to (3) M.2 2280 NVMe SSDs
Up to (3) 3.5-inch SATA HDDs
Support for Intel® Optane™ Memory
Up to (3) 3.5-inch SATA HDDs
Support for Intel® Optane™ Memory
Graphics & Connectivity
Graphics (Discrete)
NVIDIA® RTX A6000, 48 GB GDDR6
NVIDIA® RTX A5000, 24 GB GDDR6
NVIDIA® RTX A4000, 16 GB GDDR6
AMD Radeon™ Pro W6800, 32 GB GDDR6
NVIDIA® RTX A5000, 24 GB GDDR6
NVIDIA® RTX A4000, 16 GB GDDR6
AMD Radeon™ Pro W6800, 32 GB GDDR6
Ports (Front)
- USB 3.2 Gen 1 port
- USB 3.2 Gen 1 port with PowerShare
- USB 3.2 Gen 2 Type-C® port
- USB 3.2 Gen 2×2 Type-C® port with PowerShare
- Universal audio jack
Ports (Rear)
- (2) USB 2.0 ports with Smart Power On
- (2) USB 3.2 Gen 2 ports
- (2) USB 3.2 Gen 1 ports
- (2) DisplayPort 1.4 ports
- RJ-45 Ethernet port
- Audio Line-out port
Physical Dimensions
Chassis Weight
Minimum: 8.50 kg (18.739 lb) | Maximum: 15.50 kg (34.172 lb)
Dimensions
Height: 369.0 mm (14.52 in.)
Width: 173.0 mm (6.81 in.)
Depth: 420.0 mm (16.53 in.)
Width: 173.0 mm (6.81 in.)
Depth: 420.0 mm (16.53 in.)
