Description
| Specifications | |
|---|---|
| General | |
| Device Type | Switch – 8 ports – unmanaged |
| Enclosure Type | Desktop, wall-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 |
| MAC Address Table Size | 4K entries |
| Jumbo Frame Support | 9KB |
| Features | Flow control, full duplex capability, Weighted Round Robin (WRR) queuing, store and forward, Weighted Random Early Detection (WRED), Quality of Service (QoS), fanless, Energy Efficient Ethernet, 192KB packet buffer, Class of Service (CoS), security lock slot (cable lock sold separately), metal housing, DiffServ Code Point (DSCP) support |
| Compliant Standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az |
| Status Indicators | Port transmission speed, power, link/activity |
| Expansion / Connectivity | |
| Interfaces | 8 x 1000Base-T RJ-45 |
| Power | |
| Power Device | External power adapter |
| Power Consumption Operational | 4.92 Watt |
| Miscellaneous | |
| Included Accessories | Rubber feet, mounting brackets |
| MTBF | 9,727,733 hours |
| Compliant Standards | CISPR 22 Class B, cUL, EN 60950, IEC950, UL 1950, CSA 22.2 No. 950, EN50082-1, EN55022 Class B, C-Tick Class B, FCC Part 15 B, CCC, EN55024 Class B, VCCI Class B |
| Localization | Latin America, North America |
| Dimensions & Weight | |
| Width | 6.2 in |
| Depth | 4 in |
| Height | 1.1 in |
| Weight | 17.64 oz |
| Manufacturer Warranty | |
| Service & Support | Limited warranty – replacement – lifetime – response time: next business day Limited warranty – power supply – 2 years Technical support – web support – lifetime |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 – 90% (non-condensing) |
| Min Storage Temperature | -4 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 0 – 95% (non-condensing) |
